Menu parameters are for informational purposes only and cannot be changed.
All “LAST” values show the results of the last flight, even if the ECU is switched off in the
meantime. These results kept stored up to the next run of turbine.
The Statistic-Menu
Total turbine running time (excluding startups).
Number of successful turbine runs, without errors.
Number of turbine shut downs, caused by the ECU’s safety system.
Number of successful ignitions.
Number of failed ignitions.
Total fuel consumption of turbine
Number of cut off due weak battery voltage
Menu parameters are for informational purposes only and cannot be changed.
The LIMITs Menu
The LIMITs menu allows the operator to adjust the following parameters of the turbine, within the allowable
values, according to the performance requirements of a particular model.
Turbine idle speed ( If IdleRPM-SET or Idle&Ramp-Set is enabled by
Barom.Auto Tune it will further appear (Auto) in the display and
the RPM is set by ECU)
Turbine maximum speed
Indicate the thrust at full throttle. By varying the RPM this value call the related
thrust of the turbine. This provides a save and easy way to limit the maximum
thrust.
Reduced idle speed. This function is activated if the throttle stick is in idle and the
throttle trim is set to half. The Idle speed will be decreased to the programmed
value. The acceleration time to get back to the common idle speed can take 2-5
seconds according the used turbine type.
Version of ignition type:
Kerosene-N JetCat kerosene start.
This parameter is for informational purposes only and can’t be changed
Kind of connected Battery:
NiCd
LiPo 2Cell/7.4V
LiPo 3Cell/11.1V
LiFePo 3Cell/9,9V (recommend by JetCat)
Enables the ECU to align the control system according the barometric pressure.
The possible settings are:
Disabled: No auto tuning by ECU
IdleRPM-Set: Optimize of idle RPM only
Ramp-Set: Optimize of acceleration only
Idle&Ramp-Set: IdleRPM and acceleration are optimized
