PAGE 44 of 54
Only available by connected Bus-pump.
The smoke flow can be adjusted in a range of 0-100%.
Additional is shown the quantity of flow in milliliters (ml).
Battery warning function, Enabled/Disabled
Default = Disabled
Actual capacity of the fuel tank in ml
Fuel level (ml) to activate the fuel warning function.
Fuel warning function, Enabled/Disabled
Default = Disabled (OFF)
The AUX-channel (3-step switch) can be used for optionally special features or
disabled even for single-channel operation.
ON,TrbCtrl ON:
Aux channel enabled for turbine control
ON.TrbCtrl OFF:
Aux channel enabled for speed limiter functions and/or Smoker.
Turbine control disabled. The Aux channel is used only for speed limiter
and/or smoker functions. The turbine control takes place by Single Channel
Mode
NOT USED:
Single Channel Mode.
Totally disabled AUX channel input for turbine control, speed sensor and
smoker functions. AUX channel wire must not be connected to the receiver in
this mode. In case of a connected a air-speed sensor the Maximum Limit
Speed is still active and limits the maximum speed of the plane. This safety
function can’t be disabled.
Delay in seconds before Fail-Safe function will be activated.
While this time the turbine speed run on the last valid stick pulse (→HOLD)
adjustable range = 0.1 -20.0 seconds.
After expiration of this term the Fail Safe Time Out starts. (see next point)
Delay in front of Fail Save cut off.
While this time the turbine speed is set to the Fail Save RPM (next point)
Is there no valid pulse after the expiration of this term the turbine will be cut off by
the ECU. Range 0.1-20 seconds.
Programmable turbine speed for the Fail Safe Time Out procedure.
Range from minimum RPM to maximum RPM.
The ECU can directly control a smoke valve or a Smoke pump for injection of
smoke fluid into the exhaust blast to generate smoke.
You can use the shut off valve (Part# 61106-00) as smoke valve. For smoke
pump you can use any Jetcat Smokerpump
AUX-channel programming for smoke function ( 3-step switch)
Settings:
DISABLED
Smoke solenoid is not used → valve is constantly closed
Open if AuxSw=0
Smoker-valve is open if:
Turbine is running and the AUX switch (3-Pos. switch) is brought to lower position
(“off” position)
To be able to use this function its necessary that the AUX-channel func is
activated by ON,TrbCtrl Off (see above).
That is to say the Aux switch is enabled for smoke function but not for turbine
control.
Open if AuxSw=2
Smoker -valve is open if:
