PAGE 45 of 54
Turbine is running and the Aux switch (3-Pos.switch) is brought to upper position
(“AUTO-OFF” position)
To be able to use this function its necessary, that the AUX-channel func is
activated by ON,TrbCtrl Off (see above).
That is to say the Aux switch is enabled for smoke function but not for turbine
control.
If this function is activated, the smoke-valve will pulse in a sequence of 0,2 sec on
and 0,4 sec off –time if following conditions are complete:
BATTERY LOW: The valve will pulse if the ECU battery is weak/empty.
FUEL LOW: The valve will pulse if the fuel level is low the programmed
LowFuel Limit
BATT orFUEL LOW: The valve will pulse in any of this conditions
FAIL- SAVE: The valve will pulse if the ECU detect a fail safe
BATT,FUEL,FAILS: The valve will pulse in any of this conditions
ENABLESmokePmp: Enables signal for smoke pump only if turbine is running.
That is to say the pump can’t run without a running turbine
(only useful by operate a JetCat Smoke pump)
High-Temp. The valve will be pulse in case of excessive exhaust
temperature.
MaxRPM-reached: The valve will be pulsed if the turbine has reached its
maximum RPM.
Disabled: No function, off.
Note:
The smoke warn function is switched off while the throttle stick is in idle position.
Adjustment of the throttle response (acceleration) by idle (up to average speed)
Fast default setting
Normal average acceleration
Slow slow acceleration for excessive warm weather or for operate
more than 1000m sea level
Adjustment of the throttle response by full throttle (from average speed to full)
Fast default setting
Normal normal acceleration (for operation above 1000m)
Displayed flight speed unit in km/h or mph
Throttle stick curve, factory setting is 3.0 herewith the thrust and the throttle stick
position proceed proportional. At the value 1.0 the RPM proceed proportional to
the throttle stick position.
This function allows to select different start procedures.
You can decide between following settings:
SEQUENCE:
Default setting: Throttle trim to maximum, throttle stick to idle, AUX switch to
center and now move the throttle stick to maximum to start the turbine.
By using the Single Channel Mode (devoid of the AUX switch) start the turbine by
set the throttle trim to maximum and then move the throttle stick to maximum.
