PAGE 46 of 54
THROTTLE MAX:
Throttle trim and throttle stick to maximum. Turbine starts if the AUX-switch is set
to center. By Single Channel Mode (devoid of AUX switch) the turbine starts by
move the throttle more than 95% of maximum
IMMEDIATE:
The turbine starts direct by move the throttle stick to maximum and set the AUX-
switch to center.
By Single Channel Mode on move the throttle trim to maximum for start.
Suggestion to start a multi-engine model
Two channel mode:
Program one ECU to THROTTLE MAX mode but the second to SEQUENCE
mode.
The “Throttle Max turbine” starts by move the throttle trim and throttle stick to
maximum and set the AUX switch to center. To start the “Sequence turbine” you
now have to move the throttle stick first to minimum and back to maximum.
Single channel mode:
Program on turbine to IMMEDIATE the other to SEQUENCE mode.
Throttle trim and throttle stick must be set to minimum. To start the “immediate
turbine” just move the throttle trim to maximum. The “sequence turbine” starts by
move the throttle stick to maximum.
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
See chapter “Air Speed Control” of the manual
TEST Menu
Before activating the purge pump mode, ALWAYS remove the fuel feed line
connected to the turbine.
Pump Test / Purge Fuel allows the fuel pump to operate without the turbine running.
However, if the fuel feed line is not removed from the turbine during this procedure; it will
become flooded with fuel. When this occurs, the next turbine start can become highly
combustible!
Enable to prime the fuel pump and lines.
By pressing the “Change Value” key the fuel valve opens and the fuel pump starts
to run. To change the voltage the pump runs at, press either the “+” or “-“ key
while the “Change Value “ key is pressed.
By pressing the”Change Value” key the Burner glow with the appointed voltage.
The left number displays the burner voltage the right show the current battery
voltage. The burner voltage can’t be changed.
Pressing the “Change Value” key opens the burner valve
Pressing the “Change Value” key opens the smoke valve
Pressing the “Change Value” key opens the fuel valve
Displays the data of the temperature sensor. The upper left value indicate the
exhaust gas temperature, the right value call the measured value of environment.
These values are the according internal values of the AD-converter.
If appears a “F” in the upper right edge the temperature-sensor is faulty or the
data cable in not connected or faulty,too.
