68
Operation Manual
5. Press down on the valve spring retainer
and slide the spring keepers out from the
assembly (Figure 121).
6. Remove the valve spring and valve spring
retainer.
7. Remove the suction and discharge valves
(Figure 122).
8. Inspect the valves. Refer to “Valve Inspec-
tion” on page 70 for inspection criteria.
Figure 121: Spring Retainer Removal.
Keeper
Spring
Spring
Retainer
Suction
Valve
Discharge
Valve
Figure 122: Valve Removal.
To Next Page
