JLG 80SL - Hub Torque Values

SECTION 3 - CHASSIS, PLATFORM & SCISSOR ARMS
3121325 – JLG Lift – 3-5
1. Torque to 354 lb ft Dry (480 Nm)
2. Torque to 230.9 lb ft Dry (313 Nm)
3. Torque to 230.9 lb ft Dry (313 Nm)
Figure 3-3. Hub Torque Values
Drive Motor Side
1
2
3
