PowerBoost DC Converter System 1.5: Quick Start Guide

16995-01 rev. D

This document contains proprietary information. No part of this document should be reproduced

or distributed beyond its intended recipients without the express written consent of JMA Wireless. 15

Boost output #13

-48V to

lower OVP CH13

-48V input

Boost output #9

-48V to

lower OVP CH9

-48V input

LOWER boost rack contains

RETURNs for CH 9-16.

Boost output #9 RETURN to

lower OVP CH9 RETURN

Boost output #13 RETURN

to lower OVP CH13 RETURN

UPPER boost rack contains

RETURNs for CH 1-8 to lower OVP.

Note that -48V lug channel numbers progress as follows:

8 7 6 5 4 3 2 1

16 15 14 13 12 11 10 9
