PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 14
Photo below shows PB-19-SYS-16. For CH1-8, locations of -48V lugs and RETURN lugs are
the same as PB-19-SYS-8 above. For CH9-16:
-48V connections are made at upper “OMM” shelf at the locations illustrated below.
Return connections are made in similar fashion as SYS-8, but connect to the lowest
“boost” shelf.
Note: When connecting a SYS-16, tool access is often easier if the lower connections (CH9-
16) are made first.
