8.3.1 Operation Information
RunInfo, display the running information of the inverter, please refer to the
figure below.
RunInfo
InverterInfo
MotorCtrlPara
Statistic
Settings
Fault Inquiry
ESC
ENTER
ENTER
UP/DOWN
ENTER
Pin 0W
R-Mode MPPT
Iin 0A
Vin 0V
Iaout 0A
Fout 0.00Hz
Run/Stop Stop
D_Mode Auto
OF-F On
RunInfo
InverterInfo
MotorCtrlPara
Statistic
Settings
Fault Inquiry
ESC
RunInfo
Vin 230V
Iin 23.4A
Pin 456W
Fout 20.00Hz
Iaout 10.2A
Temp 26℃
ErrCode 0
StopCode 0
S_Mode Auto
D_Mode Auto
OF-F On
Run/Stop Run
ESC
Vin 230V
Iin 23.4A
Pin 456W
Fout 20.00Hz
Iaout 10.2A
Temp 26℃
ErrCode 0
StopCode 0
S_Mode Auto
D_Mode Auto
OF-F On
Run/Stop Run
ESC
ESC
RunInfo
InverterInfo
MotorCtrlPara
Statistic
Settings
Fault Inquiry
ESC
RunInfo
Figure8-6 Procedure of running data inquiry
Table8-5 RunInfo datas
RunInfo
Introduction
Vin
Inverter input voltage(V)
Iin
Inverter input current(A)
Pin
Inverter input power(W)
Fout
Inverter input current frequency(Hz)
Iaout
Inverter output A phase current(A)
Temp
Inverter radiator’s temperature(℃ )
