Optional Locking Mechanisms
If the Hookmaster is equipped with external
hydraulic locking devices, it is important that the
body has cut-outs, as shown. If not – the body
will be transported unsecured!
Manufacturer Plate
All hook-lifts have a manufacture-plate. The
information on the manufacture-plate must be
provided in the event of making a claim or when
ordering spare parts from JOAB.
The hook-lift's serial number is not just on the
manufacturer's plate, but is also stamped on
the cylinder cross-member, see image.
Design
JOAB's products are exposed to high stresses
and must therefore be very wellthought out
and of very high quality. AllJOAB'scomponents
and designs undergo comprehensive testing.
We use computer simulation to find and elim-
inate weak points and to establish the load
capacity and service life of all components.
4
About the Hookmaster | Optional Locking Mechanisms
Hookmaster manual: 13293 Edition 6 | 2021-02-22
