Function Mode
Buttons 1–12 are multifunctional. They can have three functions assigned to them. These are
related to the function mode selected for the controller (Function_1, Function_2, or Function_
3).
To select the desired function mode, simplypressbutton 12 after start-up of the controller. By
default, function mode_1 is operative at start-up. The LEDs next to buttons 11 and 12 indicate
which function mode is operative, see Table 8. If function mode 1 isactive the LEDs for buttons
11 and 12 are not illuminated.
Listed below isan overview of the buttons and their functions in relation to which function mode
has been selected.
Button Function mode 1 Function mode 2 Function mode 3
*
1 Tip – UP Trailer tip – UP ..
2 Tip – DOWN Trailer tip – DOWN ..
3 sledge – OUT Extra 1
*
..
4 sledge – IN Extra 2
*
..
5 Folding hook-post – UP Extra 3 ..
6
Folding hook-post –
DOWN
Extra 4
*
..
7 Hydraulic lock – LOCK Spreader flap – trailer
*
..
8 Hydraulic lock – OPEN Extra 6
*
..
9 Spreader flap Start motor
*
Extra 7*
10 Automatic flap Stop motor
*
Extra 8
*
11 Safety hook -- --
12 Switch function mode Switch function mode Switch function mode
Table 8: Remote control functions for electrically controlled systems
* Option: Not standard equipment.
Start the Radio Controller
Follow the instructions below to start the remote control unit.
1. Ensure that the stop button ispulled out.
2. Hold buttons 11 and 12 pressed in together untilan audible signal is heard.
25
Radio Controllers | Operation – Electrical Systems
Hookmaster manual: 13293 Edition 6 | 2021-02-22
