Continuous Hydraulic Supply
The CBW controller can be used to set and adjust a constant hydraulic feed to a tip-trailer. This
is not standard, it must be ordered as an extra option.
The hydraulic supply isnot the same as tipping or lowering a trailer. When the trailer is simply
lowered or tipped, a hydraulic feed is provided onlyduring the time the function is activated. In
contrast, the hydraulic supply is constantly fed to the tip-trailer and can be either increased or
decreased as required.
The hydraulic supply to a tip trailer isnormally fed from the hook-lift's connector on the back of
the vehicle.
The CBW controller isused to control the flow of hydraulic fluid to the tip-trailer. The flow isini-
tially set at 0L/min and must be set to the required value by the driver using the tip trailer icons.
Refer to Table 5.
Once a value for the hydraulic supplyhas been set, using the tip-trailer icons, it is saved. If the
unit or power supply isturned off, the value is stillsaved. It can be changed again, if desired, at
any time. To reset the value, activate the function and use the icons to reset it.
After setting the continuous-hydraulic-supply, it can be started by simplyselecting itsicon, as
shown below. The hydraulic supplywill flow at the saved rate of flow.
There is no hydraulic flow sensor in the supply line to the tip trailer. Therefore, an external flow
sensor will be required if the hydraulic flow isto be measured.
To operate the hydraulic supply to the tip trailer use the functions listed below.
Icon Function
Start the continuous-hydraulic-supply. The power-take-of must be active.
Increase the continuous-hydraulic-supply
Decrease the continuous-hydraulic-supply
Stop the continuous-hydraulic-supply
Table 5: Hydraulic supply to the tip trailer
17
Operation – Electrical Systems | CBW controller
Hookmaster manual: 13293 Edition 6 | 2021-02-22
