7. Fold the hook-post down toward the lifting
bracket on the body.
8. Reverse the vehicle towards the body so that the hook-post moves towards the centre of
the body’s lifting bracket. Reverse straight towards the body. If the vehicle is not reversed
straight towards the body there is a risk of missing the rollers when pulling the body onto the
Hookmaster.
9. Operate the hook-post so that it engages
with the body's lifting bracket.
10. Lockthe safety hook.
11. Run the sledge forward and lower the tip
frame when the body has passed its
centre point.
It is strictly forbidden to force or
push the body up, particularly
with heavy loads. Do not use
the ground surface to force the
body onto the vehicle.
Fast operation mode must only
be used with minimal load.
32
Loading a Body |
Hookmaster manual: 13293 Edition 6 | 2021-02-22
