0.0-0
a
b c
d
e
f
g
h
i
1-1
10 - EN
1.1 Format of this Manual
This manual contains text styles which make you pay
extra attention:
Note:
Suggestion or explanation.
CAUTION: STRESSES THAT THE FOLLOWING
ACTION MAY CAUSE DAMAGE TO THE UNIT OR
OBJECTS ATTACHED TO IT.
WARNING: STRESSES THAT THE FOLLOWING
ACTION MAY CAUSE (SEVERE) INJURY TO THE
OPERATOR OR OTHERS.
• Bulleted list:
• indicates that action must be taken by the operator
before being able to go to the next step in the sequence.
A dotted line around the number of the ! gure indicates
that this is a duplicate from a previous section.
1.2 Label of the constructor
A marking label attached to the machine shows the
following data Fig. 1-1:
a- Name and address of the manufacturer
b- EC compliance marking
c-
Y
ear of manufacture
d- Model
e- Serial number
f- Weight
g- Electric speci! cations (volt, ph, Hz, kW and A)
h- Air pressure required
i- Acoustic pressure
