2-1
H
L
P
EN - 11
2.0 Specifi cations
Electric-air tire changer for car, light commercial vehicle
and motorcycle tires designed for one-piece rims.
Weight
512 lbs (233 Kg)
Air pressure required psi 110-170 (8-12 bar)
Bead breaker force lbs 3400 (15,12 kN)
Electric specifi cations: 115 VAC, 60 Hz Single Phase
Motor power kW 0.75 (Hp 1)
Max. torque lbf·ft 738 (Nm 1000)
Turntable rotation: 7 rpm
Max. wheel diameter 40” (mm 1000)
Max. wheel width 12” (mm 305)
Rim diam. outside locking 10”-24”
Rim diam. inside locking 12”-24”
Motorcycle wheels with adapters* 8”-23”
Acoustic pressure: <70dBA
Acoustic pressure - bead seater 120dBA
Dimensions in millimeters Fig. 2-1
L= Min.-Max. width 34”1/4-42”1/2 (mm 870-1080)
P= depth 42”1/2 (mm 1080)
H= Min.-Max. height 59”1/2-70”1/2 (mm 1511-1790)
2.1 Conditions
During use or prolonged storage, conditions must never
be outside:
Temperature range
0-50 °C
Humidity range 10-90 %,
without condensation
(*) option
