5.1-7
5.1-8
5.1-9
EN - 21
• Rotate the turntable clockwise and at the same time
push down on the tire sidewall to move the bead into
the drop-center of the rim (Fig.5.1-7).
• Repeat the process for removing the lower bead. With
left hand, lift the bead in position diametrically opposite
the tool to keep it in the drop center (Fig. 5.1-8). Move
the swing arm aside and remove the tire.
The bead depressor tool “MH 310 PRO” (Accessory) can
help to facilitate demounting tires.
Position the lower disk next to the lower rim edge.
Grip the disk handle ! rmly, activate the device upstroke
and at the same time rotate the turntable (Fig. 5.1-9).
