Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Commission
(Figure 28)
Air Balance >
Return
RFPctOvr-Pos (Return Fan Percent
Override Position)
% (0–100)
Return Fan Discharge Pressure iwg
Return Fan Pressure High Setpoint iwg (0–5)
Return Fan Pressure Low Setpoint iwg (0–5)
Return Flow Value cfm
Return Pickup Gain 0–100
Return Area square feet (0–100)
RFDiffFlow-SP (Return Fan Diff Flow
Setpoint)
cfm (0–10,000)
BldgPres (Building Static Pressure) iwg
Bldg-Sp (Building Pressure Setpoint) in wc (-0.25 to 0.25)
Air Balance
> Exhaust
[Damper]
Air Balance Mode / Disable Disable, Enable
Export Air Balancing Report
UnitEn (Unit Enable) / Enable Shutdown, Enable
Air Balance
> Exhaust
[Damper]
Exhaust Damper % Command %
EDPctOvr-Mode (Exhaust Damper
Percent Override Mode) / OFF
OFF, ON
EDPctOvr-Pos (Exhaust Damper
Percent Override Position) / 0%
% (0–100)
ExDmpPosFanOn (Exhaust Damper
Position for Exhaust Fan to Turn On) / 20%
% (20–99)
ExDmpPosFanOff (Exhaust Damper
Position for Exhaust Fan to Turn Off) / 10%
% (10–89)
Exhaust Flow Value cfm
Exhaust Pickup Gain 0–100
Exhaust Area square feet (0–100)
BldgPres (Building Static Pressure) iwg
Bldg-Sp (Building Pressure Setpoint) iwg (-0.25 to 0.25)
Air Balance >
Exhaust [Fan]
Air Balance Mode / Disable Disable, Enable
Export Air Balancing Report
UnitEn (Unit Enable) / Enable Shutdown, Enable
Exhaust Fan VFD % Command %
EFPctOvr-Mode (Exhaust Fan Percent
Override Mode) / OFF
OFF, ON
EFPctOvr-Pos (Exhaust Fan Percent
Override Position) / 0%
% (0–100)
ExDmpPosFanOn (Exhaust Damper
Position for Exhaust Fan to Turn On) / 20%
% (20–99)
ExDmpPosFanOff (Exhaust Damper
Position for Exhaust Fan to Turn Off) / 10%
% (10–89)
Exhaust Flow Value cfm
Exhaust Pickup Gain 0–100
Exhaust Area square feet (0–100)
BldgPres (Building Static Pressure) iwg
Bldg-Sp (Building Pressure Setpoint) iwg (-0.25 to 0.25)
