Johnson Controls GVB Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
74
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Commission
(Figure 28)
Manual
Adjustments >
Cooling
(All of the menu
options default
to 0; allow user
to input offset to
the unit)
EVAP-T (Evaporator Temperature) delta deg F (-10 to 10)
SLP-1 (Suction Line Pressure 1) psi (-20 to 20)
LLP-1 (Liquid Line Pressure 1) psi (-20 to 20)
DLP1 (Discharge Line Pressure 1) psi (-20 to 20)
SLT-1 (Suction Line Temperature 1) delta deg F (-10 to 10)
LLT-1 (Liquid Line Temperature 1) delta deg F (-10 to 10)
DLT1 (Discharge Line Temperature 1) delta deg F (-10 to 10)
SLP-2 (Suction Line Pressure 2) psi (-20 to 20)
LLP-2 (Liquid Line Pressure 2) psi (-20 to 20)
DLP2 (Discharge Line Pressure 2) psi (-20 to 20)
SLT-2 (Suction Line Temperature 2) delta deg F (-10 to 10)
LLT-2 (Liquid Line Temperature 2) delta deg F (-10 to 10)
DLT2 (Discharge Line Temperature 2) delta deg F (-10 to 10)
Controller
(Figure 29)
Network
(Refer to
BACnet
Integration
Setup on page
94)
DevName (Displays the Device Name;
Could be Changed by User)
Address (MAC address) Refer to Table 29 on page 96
IP Address Refer to Table 28 on page 96
TimeZone / Central)
Eastern, Central, Mountain, Pacic, Newfoundland,
Atlantic, Alaska, Hawaii
Descrip (User to Enter Text, if Required)
Comm-S (Displays the Network Status)
Not Congured, Active, Waiting For Poll For
Master, Not Received Token For Long, Duplicate
MAC Address, Forcing BAUD, Remote Trunk
FCBusMode (On units with a BACnet IP
card installed, BACnet MS/TP, Modbus,
and N2 are not functional. Select one of
the available parameters.)
Wired Field Bus, Wireless Field Bus, N2 Field
Bus, Modbus Field Bus, Ethernet Field Bus,
Indeterminate FC Bus Mode
OprBaudRate (Displays the Operating
Baud Rate Used)
Auto, 1200, 9600, 19200, 38400, 76800
BaudRate (Select a Baud Rate) / 38400 Auto, 1200, 9600, 19200, 38400, 76800
IP Mask
Refer to Table 28 on page 96
IPRouterAddress
StaticIPAddress
StaticIPMask
StaticIPRouterAddress
ApplyStaticIP
DHCP-En
DeviceId Refer to Table 29 on page 96
Language / English English
Units / IP IP, SI
#NetSensors (Displays the Network
Sensors Connected in SA Bus)
Relearn (Clears the SA Bus Devices in
Memory) / False)
False, True
