Johnson Controls Hx3 S1-THXU430W User Manual

5407935-UUM-D-1119
Johnson Controls Ducted Systems 3
Figure 2 shows the tools required for installing the Hx3 Touch Screen
Thermostat. It is best practice that a qualified technician performs the
installation.
Figure 2: Tools for Installation
ScrewdriverPencil Level
Wire Strippers Drill Hammer
7/32” Drill Bit (Plaster)
3/16” Drill Bit (Drywall)
A0976-001

Johnson Controls Hx3 S1-THXU430W Specifications

General

Brand	Johnson Controls
Model	Hx3 S1-THXU430W
Category	Thermostat
Language	English
