Johnson Controls Hx3 S1-THXU430W User Manual

5407935-UUM-D-1119
24 Johnson Controls Ducted Systems
Wi-Fi Network Status
To connect the Hx3 Touch Screen Thermostat to a Wi-Fi network, you
must perform wireless setup using the Wireless Status screen and the
Hx™ Thermostat app. Follow the instructions provided in the Wi-Fi Con-
nectivity section.
To access the Wireless Status screen, tap the Wi-Fi Signal Strength
icon in the banner area. On the Wireless Status screen, you can check
Wi-Fi connectivity information. You can also disconnect from a Wi-Fi net-
work if required. To do so, tap Disconnect.
Figure 30: Wireless Status Screen
NOTICE
Your HVAC system and thermostat will operate if the Wi-Fi connection
is lost. Only Hx Thermostat app usage and software updates are
affected when offline.
Green = Connected Red = Not Connected
Connectivity Information
WIRELESS STATUS
SSID myhome_wifi-2.4
MAC 98f175bc97f
DSN AC000W000221268
REG YES
DISCONNECT
Wi-Fi
Signal
A1231-001
