Johnson Controls Metasys IFC-200 Installation Procedures

Hardware Installation—IFC-200 Hardware Installation Procedures 19
M510CJ
IFC-200
TB4 TB5 TB6
TX
REF
RX
REF
OUT OUT
IN IN
A B B+ A+ B- A-
For use with 1551J, 2551J,
and 5551J Intelligent Detectors
B501BJ Base
1
2
3
4
9
8
7
6
5
ION
THERM
Loop Address Type
2(+)
3
1(-)
M500MJ
1
2
3
4
9
8
7
6
5
M500XJ
1
2
3
4
9
8
7
6
5
1
2
3
4
9
8
7
6
5
M500XJ
Note:
M500XJ devices not
required to meet NFPA Style 6.
BGX-101 L
Connect SLC + OUT to TB6 B+ and SLC - OUT to TB6 B-
Connect SLC + OUT to TB6 A+ and SLC - OUT to TB6 A-
FIG2-7
Figure 11: Four-Wire, Style 6 SLC Communications Loop
(Supervised and Power-Limited)
