Hardware Installation—IFC-200 Hardware Installation Procedures 5
Hardware Installation
Procedures
This IFC-200 Hardware Installation Procedures Technical Bulletin is
divided into three major sections. The Hardware Installation Procedures
section contains step-by-step instructions to help you install the hardware
related to the IFC-200 Fire Control System. The Supply Calculations
section helps you determine the required current, current loads, and power
to support the IFC-200. Specific wiring information for each circuit in the
system is found in the Wire Requirements section. Read this document
before attempting to install the IFC-200 hardware.
1. Carefully unpack the system and check for shipping damage.
2. Mount the cabinet in a clean, dry, vibration-free area where extreme
temperatures are not encountered. The area should be readily
accessible with sufficient room to easily install and maintain the
panel.
3. Locate the top of the cabinet approximately five feet above the floor
with the hinge mounting on the left.
4. Determine the number of conductors required for the devices to be
installed.
5. Pull the required conductors into the box through the knockout
provided.
All wiring should be in accordance with the National and/or Local codes
for fire alarm systems.
1. Remove the main PC board assembly by unscrewing the four screws
in the corners of the board. Set the board aside in a safe, clean place.
Avoid static discharge, which may damage the board.
2. Mark and pre-drill the four mounting bolts using the dimensions
shown in Figure 1.
3. Install two upper fasteners in wall with screw heads protruding.
4. Using upper keyholes, mount the backbox over the two screws.
Tighten the screws.
5. Install the lower two screws.
6. When location is dry and free of construction dust, reinstall the main
PC board.
General
Backbox
Mounting
