Table 12: 3 ton cooling charging chart for XAH*36D and
JH(E,V)T*36D in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 207 (11) 210 (12) 212 (13) 217 (13)
60 227 (12) 230 (13) 232 (13) 236 (13)
65 247 (12) 250 (13) 252 (13) 256 (13)
70 266 (12) 270 (13) 271 (13) 276 (13)
75 286 (12) 290 (13) 291 (13) 296 (13)
80 312 (13) 315 (14) 316 (14) 321 (14)
85 338 (13) 340 (14) 342 (14) 346 (14)
90 363 (14) 365 (14) 367 (14) 371 (15)
95 389 (14) 391 (14) 393 (14) 397 (15)
100 421 (14) 423 (15) 426 (15) 429 (15)
105 454 (14) 456 (15) 459 (15) 462 (15)
110 487 (15) 488 (16) 492 (16) 495 (16)
115 520 (15) 521 (16) 524 (16) 527 (16)
120 553 (16) 554 (16) 557 (17) 560 (17)
125 585 (16) 586 (16) 590 (17) 594 (17)
Table 13: 3 ton cooling charging chart for XA(F,H)*36D
and JH(E,V)T*36D in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 196 (9) 199 (9) 201 (10) 205 (10)
60 215 (9) 218 (10) 219 (10) 223 (10)
65 233 (9) 236 (10) 238 (10) 242 (10)
70 252 (9) 255 (10) 257 (10) 261 (10)
75 270 (9) 274 (10) 275 (10) 280 (10)
80 295 (10) 298 (11) 299 (11) 303 (11)
85 319 (10) 321 (11) 323 (11) 327 (11)
90 343 (11) 345 (11) 347 (11) 351 (11)
95 368 (11) 370 (11) 372 (11) 375 (12)
100 398 (11) 400 (11) 403 (11) 406 (12)
105 429 (11) 431 (12) 434 (12) 437 (12)
110 461 (11) 462 (12) 465 (12) 468 (12)
115 492 (12) 493 (12) 496 (12) 499 (12)
120 523 (12) 524 (12) 527 (13) 530 (13)
125 554 (12) 555 (12) 559 (13) 562 (13)
Table 14: 3.5 ton cooling charging chart for
XA(F,H)*48F, XA(F,H)*60G, JH(E,V)T*42F, and
JH(E,V)T*48G in upflow or horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 203 (9) 206 (9) 209 (10) 213 (11)
60 222 (9) 225 (10) 228 (10) 232 (11)
65 241 (9) 243 (10) 246 (10) 250 (10)
70 261 (9) 262 (10) 265 (10) 269 (10)
75 280 (9) 281 (10) 283 (9) 287 (10)
80 305 (9) 305 (10) 307 (10) 311 (10)
85 329 (9) 329 (10) 331 (10) 335 (10)
90 353 (10) 354 (11) 356 (10) 359 (10)
95 377 (10) 378 (11) 380 (10) 383 (10)
100 408 (10) 408 (11) 410 (11) 413 (10)
105 439 (10) 439 (11) 441 (11) 444 (10)
110 470 (11) 470 (12) 472 (11) 474 (11)
115 501 (11) 501 (12) 503 (11) 505 (11)
120 532 (12) 532 (12) 534 (12) 536 (11)
125 563 (12) 563 (12) 565 (12) 567 (11)
Table 15: 3.5 ton cooling charging chart for
XA(F,H)*48F and JH(E,V)T*42F in downflow and
horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 197 (5) 200 (5) 203 (5) 206 (6)
60 216 (5) 218 (5) 221 (5) 225 (5)
65 234 (5) 236 (5) 239 (5) 243 (5)
70 253 (5) 254 (5) 257 (5) 261 (5)
75 272 (5) 273 (5) 275 (5) 278 (5)
80 295 (5) 296 (5) 298 (5) 302 (5)
85 319 (5) 319 (5) 321 (5) 325 (5)
90 342 (5) 343 (5) 345 (5) 348 (5)
95 365 (5) 366 (6) 369 (5) 371 (5)
100 395 (5) 396 (6) 398 (5) 401 (5)
105 425 (5) 425 (6) 427 (6) 430 (5)
110 455 (5) 455 (6) 457 (6) 460 (5)
115 485 (6) 485 (6) 487 (6) 489 (6)
120 515 (6) 515 (6) 517 (6) 519 (6)
125 545 (6) 545 (6) 547 (6) 549 (6)
R-410A Outdoor Split-System Heat Pump Installation Manual - YH2E / THE2 / RHP143 Series18
