Table 16: 4 ton cooling charging chart for XAF*60G and
JH(E,V)T*48G in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure (psig) and subcooling
(°F) at liquid base valve
55 220 (13) 224 (14) 227 (14) 231 (15)
60 241 (14) 245 (15) 247 (15) 251 (15)
65 261 (14) 265 (15) 267 (15) 271 (15)
70 281 (14) 285 (15) 288 (15) 291 (15)
75 301 (14) 305 (15) 308 (15) 311 (15)
80 327 (15) 331 (16) 333 (16) 337 (16)
85 352 (15) 356 (16) 358 (16) 362 (16)
90 378 (16) 381 (16) 384 (16) 387 (16)
95 403 (16) 406 (16) 409 (16) 412 (16)
100 435 (16) 439 (17) 441 (17) 445 (17)
105 468 (16) 472 (17) 474 (17) 478 (17)
110 500 (17) 504 (18) 507 (18) 511 (18)
115 533 (17) 537 (18) 540 (18) 544 (18)
120 566 (18) 569 (19) 573 (19) 576 (18)
125 599 (18) 602 (19) 606 (19) 609 (18)
Table 17: 4 ton cooling charging chart for XAH*60G and
JH(E,V)T*48G in horizontal left
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure(psig) and subcooling
(°F) at liquid base valve
55 223 (16) 228 (17) 231 (17) 234 (18)
60 244 (16) 248 (18) 251 (18) 255 (18)
65 265 (17) 269 (18) 271 (18) 275 (18)
70 285 (17) 289 (18) 292 (18) 295 (18)
75 305 (17) 309 (18) 312 (18) 316 (18)
80 331 (18) 335 (19) 338 (19) 341 (19)
85 357 (18) 361 (20) 363 (20) 367 (20)
90 383 (19) 386 (20) 389 (20) 392 (20)
95 409 (20) 412 (20) 415 (20) 418 (20)
100 441 (20) 445 (20) 447 (20) 451 (20)
105 474 (20) 478 (21) 480 (21) 484 (21)
110 507 (20) 511 (21) 514 (21) 518 (21)
115 540 (21) 544 (22) 547 (22) 551 (22)
120 573 (21) 577 (23) 580 (23) 584 (22)
125 607 (22) 610 (23) 614 (23) 617 (22)
Table 18: 4 ton cooling charging chart for XA(F,H)*60G
and JH(E,V)T*48G in downflow and horizontal right
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure(psig) and subcooling
(°F) at liquid base valve
55 204 (10) 208 (11) 210 (11) 214 (12)
60 223 (10) 227 (11) 229 (11) 232 (12)
65 242 (11) 246 (12) 247 (12) 251 (12)
70 260 (11) 264 (12) 266 (12) 269 (12)
75 279 (11) 282 (12) 285 (12) 288 (12)
80 302 (11) 306 (12) 308 (12) 311 (12)
85 326 (12) 329 (12) 331 (12) 335 (12)
90 349 (12) 353 (12) 355 (12) 358 (12)
95 373 (12) 376 (12) 379 (12) 381 (12)
100 403 (12) 406 (13) 408 (13) 412 (13)
105 433 (12) 437 (13) 438 (13) 442 (13)
110 463 (13) 467 (14) 469 (14) 473 (14)
115 493 (13) 497 (14) 499 (14) 503 (14)
120 523 (14) 527 (14) 530 (14) 533 (14)
125 554 (14) 557 (15) 560 (15) 563 (14)
Table 19: 5 ton cooling charging chart for XAF*60H and
JH(E,V)T*60H in upflow
Indoor wet bulb (°F) at 80°F dry bulb
57 62 67 72
Outdoor
ambient
DB (°F)
Pressure(psig) and subcooling
(°F) at liquid base valve
55 204 (10) 210 (11) 213 (12) 215 (13)
60 223 (9) 228 (11) 231 (11) 234 (12)
65 242 (9) 247 (11) 250 (11) 254 (12)
70 261 (9) 265 (10) 268 (10) 273 (11)
75 279 (9) 283 (10) 286 (10) 291 (11)
80 303 (9) 307 (10) 310 (10) 314 (11)
85 327 (9) 330 (10) 333 (10) 337 (11)
90 352 (9) 354 (10) 357 (10) 361 (11)
95 376 (10) 377 (10) 380 (10) 384 (11)
100 406 (10) 407 (10) 410 (10) 415 (11)
105 436 (10) 437 (11) 440 (11) 445 (11)
110 466 (10) 467 (11) 471 (11) 475 (11)
115 496 (11) 497 (11) 501 (11) 505 (11)
120 527 (11) 528 (11) 532 (11) 536 (11)
125 557 (11) 558 (11) 562 (11) 566 (11)
R-410A Outdoor Split-System Heat Pump Installation Manual - YH2E / THE2 / RHP143 Series 19
