JOHNSON CONTROLS
22
FORM 160.78-N1
ISSUE DATE: 5/30/2012
SECTION 2 - INSTALLATION
FIGURE 9 - FAA UNIT INSULATION
LD03827a
Bold lines and shaded components
represent insulation.
HOT GAS
LINE
SIGHT GLASS
CONDENSEREVAPORATOR EVAPORATORCONDENSER
LIQUID
LINE
HOT GAS
CONNECTION
Tape Insulation
around flanges to
allow for removal.
SIGHT GLASS
