Johnson Controls YORK YMC2 - Evaporator Nozzle Arrangements (150 Psi Compact Water Boxes); FIGURE 12 - Evaporators - Compact Water Boxes (1-Pass Nozzle Arrangements); FIGURE 13 - Evaporators - Compact Water Boxes (2-Pass Nozzle Arrangements); FIGURE 14 - Evaporators - Compact Water Boxes (3-Pass Nozzle Arrangements)

JOHNSON CONTROLS
26
FORM 160.78-N1
ISSUE DATE: 5/30/2012
SECTION 3 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
EVAPORATOR NOZZLE ARRANGEMENTS (150 PSI COMPACT WATER BOXES)
COMPACT WATER BOXES-150 PSI
Evaporator
Shell Code
Nozzle Pipe Size Ft-In (mm) Evaporator Nozzle Dimensions Ft-In (mm)
No. of Passes
C
1-Pass 2-Pass 3-Pass
1 2 3 AA
5
AA
5
BB
5
EE AA
5
BB
5
EE
EA25
8"
(203)
6"
(152)
4"
(102)
1' - 3-1/2"
(394)
1' - 10"
(559)
1' - 5"
(432)
2' - 3"
(686)
0' - 5"
(127)
1' - 5"
(432)
2' - 3"
(686)
0' - 5"
(127)
NOTE: Dimensions are shown in Inches (mm)
1-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
Right End Left End
FIGURE 12 - EVAPORATORS - COMPACT WATER BOXES (1-PASS NOZZLE ARRANGEMENTS)
LD14004
FIGURE 14 - EVAPORATORS - COMPACT WATER BOXES (3-PASS NOZZLE ARRANGEMENTS)
LD14005
2-Pass Evaporator Nozzle Arrangements
In Out
Lower Right End Upper Right End
Lower Left End Upper Left End
FIGURE 13 - EVAPORATORS - COMPACT WATER BOXES (2-PASS NOZZLE ARRANGEMENTS)
LD14007
LD14006
3-Pass Evaporator Nozzle Arrangements
In Out
Right End Left End
3-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
