JOHNSON CONTROLS
32
FORM 160.78-N1
ISSUE DATE: 5/30/2012
SECTION 3 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
FIGURE 24 - CONDENSERS - MARINE WATER BOXES (1-PASS NOZZLE ARRANGEMENTS)
LD14016
LD14019
LD14018
FIGURE 26 - CONDENSERS - MARINE WATER BOXES (3-PASS NOZZLE ARRANGEMENTS)
FIGURE 25 - CONDENSERS - MARINE WATER BOXES (2-PASS NOZZLE ARRANGEMENTS)
LD14017
MARINE WATER BOXES-150 PSI
Condenser
Shell
Code
Nozzle Pipe Size Ft-In (mm) Evaporator Nozzle Dimensions Ft-In (mm)
No. of Passes
C
1-Pass 2-Pass 3-Pass
1 2 3 AA
5
AA
5
BB
5
EE AA
5
BB
5
EE
CA21 10" (254) 6" (152) 6" (152)
1' - 3-1/2"
(394)
3' - 10-1/2"
(1181)
1' - 5-1/2"
(445)
3' - 10-1/2"
(1181)
1' - 4-1/2"
(419)
1' - 5-1/2"
(445)
3' - 10-1/2"
(1181)
1' - 4-1/2"
(419)
CA25 12 (305) 8" (203) 6" (152)
1' - 3-1/2"
(394)
4' - 0-1/2"
(1232)
1' - 5-1/2"
(445)
4' - 0-1/2"
(1232)
1' - 6-1/2"
(470)
1' - 5-1/2"
(445)
4' - 0-1/2"
(1232)
1' - 6-1/2"
(470)
NOTE: Dimensions are shown in Inches (mm)
CONDENSER NOZZLE ARRANGEMENTS (150 PSI MARINE WATER BOXES)
1-Pass Condenser Nozzle Arrangements
In Out
Left End Right End
Right End Left End
2-Pass Condenser Nozzle Arrangements
In Out
Lower Right End Upper Right End
Lower Left End Upper Left End
3-Pass Condenser Nozzle Arrangements
In Out
Right End Left End
3-Pass Condenser Nozzle Arrangements
In Out
Left End Right End
