Johnson Controls YORK YMC2 Installation Manual

JOHNSON CONTROLS
34
FORM 160.78-N1
ISSUE DATE: 5/30/2012
SECTION 3 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
TABLE 2 - APPROXIMATE UNIT WEIGHT* (MAX TUBE COUNT USING 150 PSI COMPACT WATERBOXES)
COMPRESSOR EVAPORATOR CONDENSER
SHIPPING WEIGHT
LBS (KGS)
OPERATING
WEIGHT LBS (KGS)
EST. REFRIGERANT
CHARGE LBS (KGS)
M1-197FAB
EA2510 CA2110 11770 (5339) 12740 (5779) 555 (255)
EA2510 CA2510 12790 (5802) 14070 (6383) 610 (280)
EA2514 CA2514 14970 (6791) 16620 (7539) 860 (390)
M2-205FAB
EA2510 CA2110 11790 (5348) 12760 (5788) 555 (255)
EA2510 CA2510 12810 (5811) 14090 (6392) 610 (280)
EA2514 CA2514 14990 (6800) 16630 (7544) 860 (390)
NOTE:
Refrigerant charge quantity and weights will vary based on tube count.
Shipping weight based on Form 1 shipment.
*
Refer to product drawings for detailed weight information.
TABLE 3 - EVAPORATOR MARINE WATER BOX WEIGHTS (TO BE ADDED TO STANDARD UNIT WEIGHTS
SHOWN ON TABLE 2)
EVAPORATOR
SHIPPING WEIGHT INCREASE LBS (KGS) OPERATING WEIGHT INCREASE LBS (KGS)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
EA2510 702 (318) 365 (170) 737 (334) 1192 (540) 561 (254) 1130 (515)
EA2514 702 (318) 365 (170) 737 (334) 1192 (540) 561 (254) 1130 (515)
TABLE 4 - CONDENSER MARINE WATER BOX WEIGHTS (TO BE ADDED TO STANDARD UNIT WEIGHTS
SHOWN ON TABLE 2)
CONDENSER
SHIPPING WEIGHT INCREASE (LBS) OPERATING WEIGHT INCREASE (LBS)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
CA2110 557 (263) 269 (122) 551 (249) 996 (452) 413 (187) 843 (382)
CA2510 797 (361) 403 (183) 805 (370) 1453 (659) 708 (321) 1400 (635)
CA2514 797 (361) 403 (183) 805 (370) 1453 (659) 708 (321) 1400 (635)
WEIGHTS
150 PSI Compact And Marine Water Boxes Lbs (Kgs)
