SECTION 2 - INSTALLATION
FORM 160.78-N1
ISSUE DATE: 5/30/2012
2
FIGURE 10 - FAB UNIT INSULATION
LD03827b
Bold lines and shaded components
represent insulation.
HOT GAS
LINE
SIGHT GLASS
CONDENSER EVAPORATOR EVAPORATORCONDENSER
LIQUID
LINE
HOT GAS
CONNECTION
Tape Insulation
around flanges to
allow for removal.
INSULATE LINE
