JOHNSON CONTROLS
30
FORM 160.78-N1
ISSUE DATE: 5/30/2012
SECTION 3 - DIMENSIONS, NOZZLE ARRANGEMENTS AND WEIGHTS
MARINE WATER BOXES-150 PSI
Evaporator
Shell Code
Nozzle Pipe Size Ft-In (mm) Evaporator Nozzle Dimensions Ft-In (mm)
No. of Passes
C
1-Pass 2-Pass 3-Pass
1 2 3 AA
5
AA
5
BB
5
EE AA
5
BB
5
EE
EA25
8"
(203)
6"
(152)
4"
(102)
1' - 3-1/2"
(394)
3' - 7"
(1092)
1' - 2"
(356)
3' - 7"
(1092)
1' - 5-1/2"
(445)
1' - 2"
(356)
3' - 7"
(1092)
1' - 5-1/2"
(445)
NOTE: Dimensions are shown in Inches (mm)
FIGURE 20 - EVAPORATORS - MARINE WATER BOXES (1-PASS NOZZLE ARRANGEMENTS)
LD14012
LD14015
LD14014
FIGURE 22 - EVAPORATORS - MARINE WATER BOXES (3-PASS NOZZLE ARRANGEMENTS)
FIGURE 21 - EVAPORATORS - MARINE WATER BOXES (2-PASS NOZZLE ARRANGEMENTS)
LD14013
EVAPORATOR NOZZLE ARRANGEMENTS (150 PSI MARINE WATER BOXES)
1-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
Right End Left End
2-Pass Evaporator Nozzle Arrangements
In Out
Lower Right End Upper Right End
Lower Left End Upper Left End
3-Pass Evaporator Nozzle Arrangements
In Out
Right End Left End
3-Pass Evaporator Nozzle Arrangements
In Out
Left End Right End
