Table 92: Master slot numbers
Slot number Description
8338 VGD Stroke Calibration Command
8355 VGD Fault Code
8353 VGD Actuator Fault
8354 VGD Shutdown Command
17408 Discharge Pressure
Variable speed drive
2305 Motor Run
2306 Motor % FLA
3047 VSD Fault
18085 Input % Full Load Amps
2823 VSD Output Voltage
2822 VSD Output Frequency
20788 Max Chiller Frequency
2818 Input Power
2819 Input kW Hours
2878 L1 Voltage Total Harmonic Distortion
2879 L2 Voltage Total Harmonic Distortion
2880 L3 Voltage Total Harmonic Distortion
3014 L1 Input Current Total Demand Distortion
3015 L2 Input Current Total Demand Distortion
3016 L3 Input Current Total Demand Distortion
3017 Input kVA
2869 Input Power Factor
2306 Motor % Full Load Amps
20784 VSD Command
3051 VSD Control State
3050 VSD Inverter State
3058 Precharge Active
3044 DC Bus Regulating
3057 Precharge Complete
3027 DC Bus Voltage
2829 Cooling System
3053 L1 Input Voltage (Peak)
3054 L2 Input Voltage (Peak)
3055 L3 Input Voltage (Peak)
2872 L1 Input Voltage (RMS)
2873 L2 Input Voltage (RMS)
2874 L3 Input Voltage (RMS)
3008 L1 Input Current (RMS)
3009 L2 Input Current (RMS)
3010 L3 Input Current (RMS)
3018 Phase A Output Voltage (RMS)
3019 Phase B Output Voltage (RMS)
3020 Phase C Output Voltage (RMS)
3021 Phase A Output Current (RMS)
3022 Phase B Output Current (RMS)
3023 Phase C Output Current (RMS)
3031 Phase A Rectifier Baseplate Temperature
3032 Phase B Rectifier Baseplate Temperature
3033 Phase C Rectifier Baseplate Temperature
3034 Phase A Inverter Baseplate Temperature
3035 Phase B Inverter Baseplate Temperature
3036 Phase C Inverter Baseplate Temperature
91
YMC
2
Mod B with OptiView Control Center
