Table 92: Master slot numbers
Slot number Description
3029 Internal Ambient Temperature 1
3030 Internal Ambient Temperature 2
Motor monitoring
3059 Motor Winding Phase A Temp Z1 End
3060 Motor Winding Phase A Temp Z2 End
3061 Motor Winding Phase B Temp Z1 End
3062 Motor Winding Phase B Temp Z2 End
3063 Motor Winding Phase C Temp Z1 End
3064 Motor Winding Phase C Temp Z2 End
19148 Average Winding Temperature
2362 Motor Housing Temperature
18361 Motor Housing Temperature Setpoint
18371 Motor Winding Temperature Setpoint
18362 Motor Cooling Valve Command
18396 Motor Cooling Control State
18397 Estimated Rotor Temperature
18398 Ambient Dew Point Temperature
Capacity control
2822 VSD Output Frequency
18023 HGBP Command
18041 Condenser Pressure Override Threshold
18042 Evaporator Pressure Override Threshold
18058 Head Pressure
18093 Active Anti-Surge Minimum Frequency
18122 VSD Frequency Command
18143 Input Current Override Threshold
18251 Motor Current Override Threshold
18273 Control State
18274 Active Load Limit
18288 Speed of Sound
18289 Isentropic Head
18290 Omega
18291 Surge Mach
18292 Surge Frequency (VGD Command)
18293 Anti-Surge Minimum Frequency
18295 Leaving Chilled Liquid Temperature (Filtered)
18296 Condenser Pressure (Filtered)
18297 Evaporator Pressure (Filtered)
18300 VGD Command
18332 Anti-Surge Transient Offset
18342 VGD Position
8319 Active Minimum VGD Position
18294 Surge Frequency (VGD Feedback)
Magnetic bearing controller
20992 Axial Clearance Check
20996 Axial Centering
20998 Levitation Mode
20999 Rotation Mode
21001 MBC Alarm
21002 Position V13
21003 Position W13
21004 Position V24
21005 Position W24
