Joyner JNSZ250DN - Page 32

31
1、CRANKCASE ASSY.
No. P/N ENGLISH Q’ty
19
GB/T 9877-1988 FB33X35X5 OIL SEAL FB 33X35X5
1
20
GB/T 276-1994 6201 BEARING 6201
1
21
GB/T 276-1994 620-RS BEARING 6202-RS
1
22
172MM-B-068001 HOLLOW BOLT M14X1.5
1
23
CF188-068002 WASHER 14.4X22X1
1
24
CF188-068003 SPACER SPRING
1
25
GB/T308-1989 3/8 STEEL BALL
1
152MI-130004 "O" RING FOR SEAL13.5X1.4
1
26
172MM-B-011300 ODOMETER SENSOR
1
27
172MM-B-011400 SEAL CAP
1
28
152MI-023010 BOLT M6X20
1
