Joyner JNSZ250DN - Side Cover Assy.l

32
2、SIDE COVER ASSY.L
No. P/N ENGLISH Q’ty
1
172MM-B-012001 SIDE COVER.L
1
2
172MM-B-012002 AIR DAMPER
1
3
GB/T818-2000 M6X12 SCREW
3
4
172MM-B-012005 BOLT
7
5
152MI-013008 BOLT
2
6
152MI-021005 LOCATING PIN Φ10x14
2
7
172MM-B-012003 SEAL WASHER.LEFT SIDE COVER
1
8
152MI-021018 BOLT
1
