Joyner JNSZ250DN - Transmission Gear Assy

47
14、TRANSMISSION GEAR ASSY
No. P/N ENGLISH Q’ty
1
172MM-B-067000 TRANSITION GEARS ASSY
1
2
GB/T89431-1986 20 RTAINER RING
2
3
172MM-B-067000 TRANSITION GEAR
1
4
172MM-B-067001 TRANSITON GEAR-AXIS
1
5
172MM-B-060001 MAIN AXIS
1
6
172MM-B-062000 SECONDARY AXIS ASSY
1
7
172MM-B-062006 WASHER.15X28X2
2
8
172MM-B-062002 DRIVEN GEAR.HIGH SPEED
1
9
NTN: K16X20X10 NEEDLE BEARING
2
10
172MM-B-062009 SLIDING SLEEVE.SHIFT
1
11
172MM-B-062001 SECONDARY AXIS
1
12
172MM-B-062007 WASHER 24X33X2
2
13
GB/T894.1-86-24 CIRCLIP.AXIS
1
14
K24X28X10 NEEDLE BEARING
1
15
172MM-B-062003 DRIVEN GEAR.REVERSE
1
16
172MM-B-062005 DRIVEN GEAR.OUTPUT
1
17
172MM-B-062004 DRIVEN GEAR.LOW SPEED
1
18
172MM-C-063000 OUTPUT AXIS ASSY
1
19
172MM-C-063002 WASHER 20X32X2.5
1
20
172MM-C-063005 DRIVEN GEAR.OUTPUT
1
