Joyner JNSZ250DN - Clutch Assy

45
12、CLUTCH ASSY
No. P/N ENGLISH Q’ty
1
172MM-052008 BOLT M12X1.25
1
2
172MM-A-052500 OUTTER WHEEL DISC
1
3
172MM-052005 THIN NUT M30X1
1
4
172MM-A-052400 DRIVE PAN UNIT
1
5
172MM-A-052200 DAMPING RUBBER BLOCK
3
6
172MM-A-052600 CLUTCH BLOCK
3
7
172MM-A-052006 RELEASE SPRING
3
8
172MM-A-052003 SIDE PAN
1
9
GB/T896-1986-9 SPLIT WASHER
3
10
172MM-052310 NEEDLE BEARING
1
11
GB/T893.1-1986-28 RETAINER RING.HOLE
1
12
GB/T278-1989-1060902 BEARING
1
13
172MM-A-052300 DRIVEN PAN UNIT
1
14
172MM-A-052001 GALLOWS ROLL
4
15
172MM-A-052104 GREASE SEAL.DRIVEN PAN
2
16
172MM-A-052100 MOVABLE DRIVEN PAN
1
17
GB/T3452.1-1992-46.2X1.8 "O" SEAL RING
2
18
172MM-A-052007 SEAL BUSHING
1
19
172MM-A-052004 CLUTCH SPING
1
20
172MM-A-052009 SLEEVE
1
21
172MM-A-052002 GUIDE PIN
4
22
172MM-B-053000 COG BELT
1
