Joyner JNSZ250DN - Coolant Pump Assy

51
17、COOLANT PUMP ASSY
No. P/N ENGLISH Q’ty
1
172MM-080004 IMPELLER.WATER PUMP
1
2
152MI-081000 WATER SEAL ASSY
1
3
172MM-080003 WATER PUMP COVER
1
4
172MM-080002 SEAL WASHER. COVER
1
5
172MM-080001 WATER PUMP AXIS
1
6
152MI-013009 BOLT M6X40
2
7
152MI-021017 BOLT M6X25
2
8
GB/T893.1-1986-19 RETAINER RING.HOLE
1
9
152MI-080007 WASHER.7.5X13X1.2
1
10
152MI-080011 WASHER.6X12X1
1
11
NTN: 6800 NEEDLE BEARING
2
12
172MM-080005 GREASE SEAL 10X20X5
1
13
152MI-080008 LOCATION PIN Φ8X14
2
14
15
16
17
18
19
20
21
22
