Joyner JNSZ250DN - Admission Machanism

42
9、ADMISSION MACHANISM
No. P/N ENGLISH Q’ty
1
152MI-022500 SEAL.VALVE ROD
2
2
172MM-022300 CAM UNIT
1
3
152MI-021007 SWING ARM
2
4
172MM-022001 INTAKE VALVE
1
5
172MM-022005 EXHAUST VALVE
1
6
172MM-022002 VALVE SPRINGL.OUTTER
2
7
172MM-022003 VALVE SPRINGL.INNER
2
8
152MI-022005 PAN.VALVE SPRING
2
9
152MI-022001 SEAT.VALVE SPRING
2
10
152MI-022006 CLAMP.VALVE
4
11
NTN: 16002 BALL BEARING
2
12
GB894.A-1-86-15 AXIS RETAINER RING
1
13
172MM-022310 CHAIN PULLY
1
14
172MM-022301 CAM AXIS
1
