Joyner JNSZ250DN - Gearbox Cover Assy

46
13、GEARBOX COVER ASSY
No. P/N ENGLISH Q’ty
1
172MM-C-060001 COVER.GEARBOX
1
2
172MM-C-060002 PAPER WASHER.GEARBOX
1
3
172MM-013005 BOLT M12X1.5.OIL OUTLET
1
4
152MI-021014 WASHER12
1
5
172MM-B-069000 SHIFT DISPLAY SWITCH
1
6
GB/T 276-1994 6202-RS BALL BEARING
1
7
GB/T 276-1994 6201 BALL BEARING
1
8
GB/T 276-1994 6203 BALL BEARING
1
9
GB/T 276-1994 6305-RS BALL BEARING
1
10
172MM-B-011107 BOLT M8X48
3
11
172MM-B-011111 BOLT M8X30
5
12
1P52MI-A-011007 BOLT M8X55
2
13
CF188-332004 "O" RING 19X2.5
1
14
CF188-332003 BOLT.OIL INLET
1
15
172MM-C-060003 OIL SEAL 32X62X7
1
16
CF188-310028 JOINT.AIR PIPE
1
17
152MI-080008 LOCATION PIN Φ8X14
2
18
172MM-C-060007 PAPER WASHER.
1
19
172MM-C-060006 CHAIN PULLY COVER
1
20
GB5787-86 M6X40-D·Cr BOLT
3
21
152MI-080012 BOLT M6X32
3
22
CF188-065002 OIL SEAL SD 15X25X5
1
23
172MM-B-011113 OIL STOP CHIP
1
24
GB/T 819-2000 SCREW M4X12
2
