Joyner JNSZ250DN - Cylinger Body Assy

39
6、CYLINGER BODY ASSY
No. P/N ENGLISH Q’ty
1
172MM-023100 CYLINDER
1
2
172MM-023002 SEAL WASHER.CYLINDER
1
3
152MI-023300 TENSIONER UNIT
1
4
152MI-023307 BOLT.SPRING SEAT
1
5
152MI-023306 SPRING.TENSIONER
1
6
152MI-023004 SEAL WASHER.TENSIONER
1
7
172MM-023007 RUBBER PIPE.WATER INLET
1
8
172MM-023009 JACKET.WATER PIPE
1
9
QC/T621-1999-B24 STEEL BAND CLAMP
2
10
152MI-023305 WASHER 8.5
1
11
GB/T848-85-6-D·ZN SMALL WASHER
1
12
152MI-021005 LOCATION PIN Φ10X14
2
13
152MI-023008 BOLT M6X18
2
14
152MI-080013 BOLT M6X22
1
