Joyner JNSZ250DN - Cylingder Head Assy

37
5、CYLINGDER HEAD ASSY
No. P/N ENGLISH Q’ty
1
172MM-022100 CYLINDER HEAD
1
2
172MM-022700 FLANGE.EXHAUST
1
3
152MI-022014 BEARING COVE.CAM AXIS
1
4
172MM-022008 NUT.EXHAUST
2
5
172MM-022010 SEAL WASNER.CYLINDER HEAD
1
6
172MM-022900 CARBURETOR SEAT UNIT
1
7
172MM-022500 CLAMP UNIT.AIR INLET PIPE
1
8
152MI-022810 THERMOSTAT
1
9
152MI-022803 THERMOSTAT SHELL.UPPER
1
10
152MI-022021 RUBBER PIPE1.CARBURETOR
1
11
172MM-022601 THERMOSTAT SHELL.LOWER
1
12
172MM-022400 SPARK PLUG
1
13
152MI-022017 BOLT M6X25
2
14
172MM-022800 SEAL WASHER. BREATH
1
15
152MI-022600 WATER TEMP SENSOR
1
16
GB/T6191-1986-M6X18-D·Cr SOCKET HEAD SCREW
2
17
172MM-022007 DOUBLE-SCREW BOLT
2
18
152MI-022012 WASHER 8
4
19
152MI-022013 CAP NUT M8
4
20
152MI-022804 "O" RING 14.8X1.9
1
21
172MM-022009 "O" RING 31X2
1
22
152MI-022020 BOLT M6X22
2
23
152MI-021005 LOCATION PIN Φ10X14
2
