JRC JAN-7201 - Page 298

Appendix B Menu List and Materials B-118
B.7.1 Symbol
Category name Object name
Icon button display
example
Alert generated when
the own ship approaches
the object
(General) Circle No alert
Triangle No alert
Square No alert
Diamond No alert
Multiple mark No alert
Warning symbol Crossing a danger
(dangerous symbol)
(Manual Update) Delete symbol No alert
(Anchor) Anchor Point No alert
Anchorage Area No alert
Anchor Berth No alert
Anchor Prohibited Area No alert
Barrel buoy (No object name) Crossing a danger
(dangerous symbol)
Light flare, default Crossing a danger
(dangerous symbol)
Light flare, red Crossing a danger
(dangerous symbol)
Light flare, green Crossing a danger
(dangerous symbol)
Light flare, white/yellow Crossing a danger
(dangerous symbol)
