B.10 Data Format of the File that can be
Imported/Exported in the ECDIS
B.10.1 File Types
• Route file
• User chart file
• Logbook file
B.10.2 File Name
File name in device Factory setting exported file name
Route file * .csv, * . * , * . rtm , * .
rta , * . rtn
The file name that is specified by the user in “File
name” of the [Export] dialog is used.
The default “File Type” is *.rtm and as other
types, *.rta, *.rtn, and *.csv are available.
User chart file * . csv , * .uchm -
Log book file
- Specified period
- Logbook_(Specified start date _end date).csv
Example: Logbook_020312_020313.csvl
B.10.3 CSV File Data Structure
• At import, lines starting with “//” are processed as comments.
• Commas are used as delimiters.
Example:
// SYMBOL,InstName,,,,,,
// Comment
// Lat,,,Lon,,
SYMBOL,BOYSHP01,,
User Comment
30,6.433,N,129,35.583,E
