5-1
Section 5 Operation
5.1 Menu List
5.1.1 Menu List
MAIN MENU
├
DISPLAY ┬ CONTRAST 1～7～13
│ ├ DIMMER ┬ MAXIMUM 1～9～10
│ │ ├ TYPICAL 1～6～10
│ │ └ MINIMUM 1～4～10
│ ├ CLICK SOUND ON/OFF
│ └ REVERSING MODE NORMAL,REVERSE1,REVERES2
│
├ HEADING ┬ RESTORATION AUTO,MANUAL
│ ├ BACKUP 1,2,3,4,5min
│ ├ INTERRUPT NMEA NULL,LAST,STOP
│ ├
HEADING CHECK
SUM
ON,OFF
│ ├ HEADING OFFSET `-10°～0°～+10°
│ ├
OUTPUT
RESOLUTION
0.1,0.01°
│ └ MAGNET ON,OFF
│
├ GPS ┬ MODE AUTO,2D,3D
│ ├ HDOP 4,10,20
│ ├ SMOOTHING ┬ POSITION 0～10～99s
│ │ ├ SPEED(SOG) 0～4～99s
│ │ └ COURSE(COG) 0～4～99s
│ ├ RAIM ACCURACY LEVEL OFF,10,30,50,100m
│ └ INITIALIZATION ┬ LATITUDE
│ ├ LONGITUDE
│ ├ ANT HEIGHT
│ ├ DATE DD-MM’YY
│ └ UTC HH:MM:SS
│
├ SBAS ┬ MODE AUTO,GPS ALONE,SBAS,BEACON
│ ├ SBAS SEARCH AUTO,MANUAL
│ ├
TYPE 0
INFORMATION
ON,OFF
│ └ RANGING ON,OFF
│
├ BEACON ┬ STATION SELECT MANUAL,AUTO
│ ├ BIT RATE 50,100,200bps
│ ├ FREQUENCY 275.0～325.0kHz
│ └ BEACON INFORMATION ON,OFF
│
├ SYSTEM ┬ TIME DIFF `-13:00～00:00～+13:00
│ ├ DATE DISP DD-MM’YY,’YY-MM-DD,MM-DD’YY
│ ├ TIME DISP 12,24
│ ├ DATUM WGS84,WGS72,JAPAN,………PUR
│ ├ SPEED UNIT kt,km/h,mi/h
│ ├ ROT RANGE ┌ ±30,60,90,120,150,180,
│ │ │ 210,240,270,300,600,900,
│ │ └ 1200,1500,1800,2100,2400,2700°/min
│ ├ ROT SMOOTHING 0～10～99s
│ ├ ROLL/PITCH RANGE ±5,10,15,20,25,30°
│ ├ ROLL OFFSET `-30～0～+30°
│ └ PITCH OFFSET `-30～0～+30°
│
├ DATA I/O ┬ SENSOR THROUGH NMEA,AD-10,NSK,JRC
│ ├ DATA OUT1 NMEA,AD-10,NSK
│ ├ DATA OUT3 NMEA,NSK
│ ├ DATA OUT4/IN4 NMEA/OFF,NSK/OFF,BEACON/OFF,NMEA/CURRENT,
│ │ BEACON/CURRENT
│ ├ DATA OUT5 NMEA,NSK
│ └ LOG PULSE OFF,200p/nm,400p/nm
│
