JRC JLR-20 - 5.2 Basic Operation; 5.2.1 Turning the Unit On

5-3
5.2 Basic Operation
5.2.1 Turning the Unit On
Press the key to turn the power on, the system starts initialization.
Once initialization has been completed, self-diagnosis will run when the equipment condition has been
checked, the screen switches to the standard screen.
If the unit cannot be turned on, check the main power supply and the connection of display unit
cable.
Press the key to break the self-diagnosis and display the standard screen.
5.2.1.1 Startup (Standard)
If the self-diagnosis results are all "OK", the unit automatically switches to the standard screen.
Attention
Memo
Unit Initialization
Self-Diagnosis Screen
Display Unit
Diagnosis
Sensor Diagnosis
OK
OK
O
K
OK
OK
OK
OK
OK
OK
OK
OK
O
K
OK
OK
OK
OK
OK
OK
Standard Screen
Self-Diagnosis Screen
