5-17
5.3.3 GPS Configuration (GPS)
Selecting GPS from the "5.3 Main Menu" displays the GPS Settings Screen.
From this screen, the parameters for the sensor can be confirmed.
1. Press the keys to move the cursor and select an item.
2. Press the key to display the menu for the selected item.
The following submenus are available.
• MODE AUTO: 2D and 3D position fix automatically switched.
Normally, the setting should be left AUTO.
2D The position is fixed in two-dimensional measurement.
3D: The position is fixed in three-dimensional measurement.
• HDOP: 4, 10, or 20 can be selected. Normally, the setting should be left
10.
• SMOOTHING POSITION: Can be set between 0 and 99.
SPEED: Can be set between 0 and 99.
COURSE: Can be set between 0 and 99.
• RAIM ACCURACY LEVEL: Off, 10, 30, 50, or 100 can be selected.
• INITIALIZATION: Displays the Initial Settings Screen. This is used for initial settings
for the GPS receiver. This item is not normally used.
• Press to return to the Main Menu.
• In Maintenance Mode settings can be change press and hold both and for 3
seconds or more to go to the mode.
GPS Settings Menu
Procedure
Memo
