5-19
5.3.4 SBAS Settings (SBAS)
Selecting SBAS from the "5.3 Main Menu" displays the SBAS Settings Screen.
From this screen, the parameters for the sensor can be confirmed.
1. Press the keys to move the cursor and select an item.
2. Press the key to display the menu for the selected item.
The following submenus are available.
• MODE: Select the position correction mode.
AUTO: Beacon, SBAS, or GPS Only will be selected automatically for
measurement according to the status of signal reception.
(In order of : Beacon → SBAS → GPS only)
GPS ALONE: Position is fixed by GPS only.
SBAS or beacon measurement will not be performed.
SBAS: SBAS takes the priority of measurement.
Switched automatically to “GPS Only” when SBAS information is
not obtained.
BEACON: The beacon takes the priority of measurement.
Switchied automatically to “GPS Only” when Beacon information is
not obtained.
• SBAS SEARCH: AUTO or MANUAL can be selected.
When MANUAL is selected, the following TYPE 0 INFORMATION must be set.
• TYPE 0
INFORMATION: Test broadcast data can be turned on (for use) or off (when not in use).
(When broadcasting starts, the broadcast data overrides, and this item is
disabled)
• RANGING: ON or OFF can be selected.
Used when an SBAS satellite is used with a GPS satellite.
Normally, the setting should be left ON.
• Press to return to the Main Menu.
• In Maintenance Mode settings can be changed press and hold both and for 3
seconds or more to go to the mode.
SBAS Settings Menu
Procedure
Memo
