6.3 Troubleshooting
6.3.1 Troubleshooting
WARNING
Do not perform internal inspections or modifications of the equipment.
Inspection or modification by unauthorized personnel may result in fire, electric
shock, or equipment failure. Please consult with JRC or an affiliate to perform
internal inspections or repair.
The following is reference information concerning identification of problems.
Problem Behavior Possible Causes Troubleshooting Measures
Power is not being supplied
by the ship junction box.
Check the cabling from the junction
box.
Power is not being supplied
by the power supply
equipment (option).
Check the power supply unit cabling.
The fuse connected to the
power cable has blown.
If there are no problems in the cabling,
replace the fuse.
The power supply equipment
(option) fuse has blown.
If there are no problems in the cabling,
replace the fuse.
The power does not turn on
when the power switch is
pressed.
The display unit switch is
broken.
Consult with JRC or an affiliate
.
The LCD display does not
display anything.
The display does not light
up.
The LCD display is broken. Consult with JRC or an affiliate.
The alarm sound. Is not
generated
The buzzer is broken. Consult with JRC or an affiliate.
The click does not sound. The key press sound is
turned off.
Refer to 5.3.1.3 for setting the key
press sound.
The sensor connection cable
is cut.
Check the connection cable. There is no reception.
(from sensor)
The sensor is broken. Consult with JRC or an affiliate.
The polarity of the serial
cable is incorrect.
Check the polarity of the cable.
The interface does not
match.
Check the interface.
There is no reception.
(from external devices)
An unsupported sentence
has been entered.
Check the entered commands and
version.
Output settings have not
been configured.
Refer to 5.3.7 for setting the key press
sound.
The configured channel is
incorrect.
Refer to 5.3.7 for setting the key press
sound.
There is no transmission.
(to external devices)
The DISP-DPU or
connector board is broken.
Consult with JRC or an affiliate.
