JRC JLR-30 User Manual

1-2
1.3 Configuration
Standard Configuration
JLR-20
No. Name Model/Code Q’ty Notes
1 Display Unit NWZ-4700 1
1-1 Power Cable CFQ-7257 1 2m / With fuse holder
1-2 Fuse MF60NR 250V 2 2 2Amps.
1-3 Clamp Filter TFC-23-11-14 1 5MBAT00002
1-4 Model Identification Plate MPNN44124 1
1-5 Installation Screws MPTG31659 1 4 tapping screws
1-6 Flush Mounting Screw Kit MPTG31962 1 4 screws
2 Sensor Unit NNN-20 1
2-1 Cable CFQ-7248 1 10m / 14 cores
2-2 Clamp Filter (Small) E04SR200935A 2
2-3 Clamp Filter (Large) E04SR301334 1
2-4 Bundling Band (Short) 1
2-5 Bundling Band (Long) 4
2-6 Self-bonding Tape 1
3 Instruction Manual (English) 7ZPNA4026 1
JLR-30
No. Name Model/Code Q’ty Notes
1 Display Unit NWZ-4700 1
1-1 Power Cable CFQ-7257 1 2m / With fuse holder
1-2 Fuse MF60NR 250V 2 2 2Amps.
1-3 Clamp Filter TFC-23-11-14 1 5MBAT00002
1-4 Model Identification Plate MPNN44124 1
1-5 Installation Screws MPTG31659 1 4 tapping screws
1-6 Flush Mounting Screw Kit MPTG31962 1 4 screws
2 Sensor Unit NNN-30 1
2-1 Cable CFQ-7248 1 10m / 14 cores
2-2 Clamp Filter (Small) E04SR200935A 2
2-3 Clamp Filter (Large) E04SR301334 1
2-4 Bundling Band (Short) 1
2-5 Bundling Band (Long) 4
2-6 Self-bonding Tape 1
3 Instruction Manual (English) 7ZPNA4026 1
Option
No. Name Model/Code Q’ty Notes
1 AC Power Rectifier NBA-3747 1
AC100 / 220V
2 Data Cable CFQ-5374 1
3m / 12 cores / Serial data
transmission
3 Data Cable CFQ-5404 1
3m / 14 cores / Dry contact signal
4 Extension Cable CFQ-7249 1
20m / 14 cores / For sensor extension
5 Beacon Connecting Cable CFQ-7250 1
For beacon receiver connection
6 Junction Box NQE-7720 1
14 connector / for sensor extension
7 GPS Repecon NQA-4115T 1 Digital/Synchronous Converter
8 DGPS Receiver JLR-4331 1 Integrates the DGPS beacon receiver
9 Mount MPBX44117 1 For NNN-20
