JRC JLR-30 User Manual

9-1
Section 9 Specifications
9.1 DISPLAY UNIT (NWZ-4700)
9.1.1 Panel
(1) Display Unit: 5.7 inch FSTN LCD, 320 x 240 dots
(2) Operating Keys: 12 keys
(3) Backlight (LED): LCD and key lighting
(4) Dimmer Levels: Bright, medium, dark, off
9.1.2 Power Supply
(1) Power Supply Voltage: 12/24 VDC (+30%, -10%)
(2) Power Consumption: Maximum 12W (including sensor)
Maximum 6W (except sensor)
9.1.3 Environment
(1) Operating Temperature: -15ºC to +55ºC
(2) Storage Temperature: -25ºC to +70ºC
(3) Waterproofing: IPX4
(4) Vibration: IEC60945 ed.4 conformant
(5) EMC: IEC60945 ed.4 conformant
9.1.4 Dimensions and Mass
(1) Dimensions: 267.4mm (W) X 162mm (H) X 85mm (D)
Except projections
(2) Mass: Approximately 2.3 kg
